产品描述
类别名称Type designation | TW-PVJB01-ab | ||
额定电压Rated voltage | 1500V DC | 阻燃等级 Flame class | UL94-V0 |
额定电流 Rated current | 25A/30A | 线缆规格Cable specifications | 1*4mm² |
环境温度范围 Ambient temperature range | -40℃~ +85 ℃ | 安全等级 Safety class | Ⅱ |
防护等级Degree of protection | IP68 | 火焰等级 Flame class | 5VB |
接触材料Contact material | T2 镀锡 T2-Sn | 连接器 Connector | TW-PVCON-01 |
绝缘材料Insulation material | PPO 9406P | 二极管型号 Diode type | 35SQ045 for 25A |
40SQ045 for 30A | |||
